The G4 Toggle Power Switch is a mechanical switching device commonly used in electronics and electrical projects
Specifications
Toggle switch: Manual flip-action switch
Position: 2-position (ON-OFF or ON-ON)
Configuration: DPDT (Double Pole Double Throw)
Model designation: G4 series
Voltage rating: Typically 125V AC or 250V AC
Current rating: Usually 3A to 6A (depends on manufacturer)
Contact resistance: < 50mΩ
Insulation resistance: > 100MΩ
Dielectric strength: Typically 1000V AC/minute
Application
Power control: Main power ON/OFF for devices
Polarity reversal: DC motor direction control
Circuit switching: Toggling between two circuits
Audio/video routing: Switching between inputs/outputs
Battery bank switching: Alternating between power sourcesLight control: Two-way lighting circuits
Equipment mode selection: Switching between operating modes
